Surface Mount Ultra Fast Recovery High Voltage Diodes deliver exceptional switching performance, packaged in compact SMD formats for modern PCB designs.

Types of Surface Mount Ultra Fast Recovery High Voltage Diode

Quickly Find the Products You Need
Part #
Reverse Repetitive Peak Voltage
kV
Average Forward Current
mA
Reverse Recovery Time
ns
Part #
Rep. Peak Reverse Voltage

VRRM (kV)

 Average Forward Current

IF(AV) (mA)

 Max. Peak Forward Voltage

VFM (V)

 Max. Forward Surge Current

IFSM (A)

 Max. Reverse Current

@ 25℃

 Max. Reverse Current

@ 100℃

 Reverse Recovery Time

trr (ns)

 Package Code
Detail
UA1A2 2 1000 8 20 1 15 50 HVS-304E View Detail
AUC1A5-2 2 1500 8 60 1 30 50 HVS-408E View Detail
AUC2A-2 2 2000 8 60 1 30 50 HVS-408E View Detail
AUX3A-2 2 3000 8 80 1 50 50 HVS-607E View Detail
AUX4A-2 2 4000 8 80 1 50 50 HVS-607E View Detail
UA423 3 400 10 10 1 15 50 HVS-304E View Detail
UA523 3 500 10 15 1 15 50 HVS-304E View Detail
UA623 3 600 10 15 1 15 50 HVS-304E View Detail
UA823 3 800 10 20 1 15 50 HVS-304E View Detail
AUC8203 3 800 10 40 1 20 50 HVS-408E View Detail
UA1A3 3 1000 10 20 1 15 50 HVS-304E View Detail
AUC1A-3 3 1000 10 60 1 30 50 HVS-408E View Detail
AUC1A5-3 3 1500 10 60 1 30 50 HVS-408E View Detail
AUC2A-3 3 2000 10 60 1 30 50 HVS-408E View Detail
AUX2A-3 3 2000 10 80 1 40 50 HVS-607E View Detail
AUX3A-3 3 3000 10 80 1 50 50 HVS-607E View Detail
AUX4A-3 3 4000 10 80 1 50 50 HVS-607E View Detail
UA424 4 400 12 10 1 15 50 HVS-304E View Detail
UA524 4 500 12 15 1 15 50 HVS-304E View Detail
AUC5204 4 500 12 40 1 20 50 HVS-408E View Detail
UA624 4 600 12 15 1 15 50 HVS-304E View Detail
AUC6204 4 600 12 40 1 20 50 HVS-408E View Detail
AUC8204 4 800 12 40 1 20 50 HVS-408E View Detail
AUC1A-4 4 1000 12 60 1 30 50 HVS-408E View Detail
AUX1A-4 4 1000 12 60 1 40 50 HVS-607E View Detail
AUC1A5-4 4 1500 12 60 1 30 50 HVS-408E View Detail
AUX2A-4 4 2000 12 80 1 40 50 HVS-607E View Detail
AUX3A-4 4 3000 12 80 1 50 50 HVS-607E View Detail
UA125 5 100 10 10 1 15 50 HVS-304E View Detail
UA225 5 200 12 10 1 15 50 HVS-304E View Detail
UA325 5 300 14 10 1 15 50 HVS-304E View Detail
UA425 5 400 14 10 1 15 50 HVS-304E View Detail
AUC4205 5 400 14 30 1 20 50 HVS-408E View Detail
UA525 5 500 16 20 1 20 50 HVS-304E View Detail
AUC5205 5 500 14 40 1 20 50 HVS-408E View Detail
AUC6205 5 600 14 40 1 20 50 HVS-408E View Detail
AUC8205 5 800 16 40 1 30 50 HVS-408E View Detail
AUX8205 5 800 16 40 1 40 50 HVS-607E View Detail
AUC1A-5 5 1000 16 60 1 30 50 HVS-408E View Detail
AUX1A-5 5 1000 16 60 1 40 50 HVS-607E View Detail
AUX2A-5 5 2000 14 80 1 50 50 HVS-607E View Detail
UA126 6 100 12 10 1 15 50 HVS-304E View Detail
AUC1206 6 100 12 10 1 15 50 HVS-408E View Detail
UA226 6 200 14 10 1 15 50 HVS-304E View Detail
AUC2206 6 200 14 15 1 15 50 HVS-408E View Detail
UA326 6 300 16 10 1 15 50 HVS-304E View Detail
AUC3206 6 300 16 20 1 20 50 HVS-408E View Detail
AUC4206 6 400 16 30 1 20 50 HVS-408E View Detail
AUC5206 6 500 16 40 1 20 50 HVS-408E View Detail
AUC6206 6 600 16 40 1 20 50 HVS-408E View Detail
AUG6206 6 600 16 40 1 20 50 HVS-412E View Detail
AUC8206 6 800 18 40 1 30 50 HVS-408E View Detail
AUX8206 6 800 18 40 1 40 50 HVS-607E View Detail
AUX1A-6 6 1000 18 60 1 40 50 HVS-607E View Detail
AUX2A-6 6 2000 16 80 1 50 50 HVS-607E View Detail
UA128 8 100 16 10 1 15 50 HVS-304E View Detail
AUC1208 8 100 16 10 1 15 50 HVS-408E View Detail
AUG1208 8 100 16 10 1 15 50 HVS-412E View Detail
UA228 8 200 16 10 1 15 50 HVS-304E View Detail
AUC2208 8 200 16 15 1 15 50 HVS-408E View Detail
AUG2208 8 200 16 15 1 15 50 HVS-412E View Detail
AUC3208 8 300 18 20 1 20 50 HVS-408E View Detail
AUG3208 8 300 18 20 1 20 50 HVS-412E View Detail
AUC4208 8 400 18 30 1 20 50 HVS-408E View Detail
AUG4208 8 400 18 30 1 20 50 HVS-412E View Detail
AUC5208 8 500 18 40 1 20 50 HVS-408E View Detail
AUG5208 8 500 18 40 1 20 50 HVS-412E View Detail
AUX5208 8 500 18 40 1 40 50 HVS-607E View Detail
AUC6208 8 600 18 40 1 20 50 HVS-408E View Detail
AUG6208 8 600 18 40 1 20 50 HVS-412E View Detail
AUX6208 8 600 18 40 1 40 50 HVS-607E View Detail
AUX8208 8 800 20 40 1 40 50 HVS-607E View Detail
AUX1A-8 8 1000 20 60 1 50 50 HVS-607E View Detail
AUC1210 10 100 20 10 1 15 50 HVS-408E View Detail
AUG1210 10 100 20 10 1 15 50 HVS-412E View Detail
AUC2210 10 200 20 15 1 15 50 HVS-408E View Detail
AUG2210 10 200 20 15 1 15 50 HVS-412E View Detail
AUC3210 10 300 22 20 1 20 50 HVS-408E View Detail
AUG3210 10 300 22 20 1 20 20 HVS-412E View Detail
AUC4210 10 400 22 30 1 20 50 HVS-408E View Detail
AUG4210 10 400 22 30 1 20 50 HVS-412E View Detail
AUC5210 10 500 22 40 1 20 50 HVS-408E View Detail
AUG5210 10 500 22 40 1 20 50 HVS-412E View Detail
AUX5210 10 500 22 40 1 40 50 HVS-607E View Detail
AUG6210 10 600 22 40 1 20 50 HVS-412E View Detail
AUX6210 10 600 22 40 1 40 50 HVS-607E View Detail
AUX8210 10 800 22 40 1 50 50 HVS-607E View Detail
AUX1A-10 10 1000 22 60 1 50 50 HVS-607E View Detail
AUC1212 12 100 22 10 1 15 50 HVS-408E View Detail
AUG1212 12 100 22 10 1 15 50 HVS-412E View Detail
AUC2212 12 200 22 15 1 15 50 HVS-408E View Detail
AUG2212 12 200 22 15 1 15 50 HVS-412E View Detail
AUC3212 12 300 24 20 1 20 50 HVS-408E View Detail
AUG3212 12 300 24 20 1 20 50 HVS-412E View Detail
AUC4212 12 400 24 30 1 20 50 HVS-408E View Detail
AUG4212 12 400 24 30 1 20 50 HVS-412E View Detail
AUC5212 12 500 24 40 1 20 50 HVS-408E View Detail
AUG5212 12 500 24 40 1 20 50 HVS-412E View Detail
AUX5212 12 500 24 40 1 40 50 HVS-607E View Detail
AUG6212 12 600 24 40 1 20 50 HVS-412E View Detail
AUX6212 12 600 24 40 1 40 50 HVS-607E View Detail
AUX8212 12 800 26 40 1 50 50 HVS-607E View Detail
AUC1215 15 100 26 10 1 15 50 HVS-408E View Detail
AUG1215 15 100 26 10 1 15 50 HVS-412E View Detail
AUC2215 15 200 26 15 1 15 50 HVS-408E View Detail
AUG2215 15 200 26 15 1 20 50 HVS-412E View Detail
AUC3215 15 300 26 20 1 20 50 HVS-408E View Detail
AUG3215 15 300 26 20 1 20 50 HVS-412E View Detail
AUG4215 15 400 28 30 1 20 50 HVS-412E View Detail
AUG5215 15 500 28 40 1 20 50 HVS-412E View Detail
AUG1220 20 100 35 10 1 15 50 HVS-412E View Detail
AUG2220 20 200 35 15 1 20 50 HVS-412E View Detail
AUG3220 20 300 37 20 1 20 50 HVS-412E View Detail
AUG1225 25 100 42 10 1 15 50 HVS-412E View Detail
AUG2225 25 200 42 15 1 20 50 HVS-412E View Detail
AUG1230 30 100 50 10 1 15 50 HVS-412E View Detail
AUG2230 30 200 50 15 1 20 50 HVS-412E View Detail
